8Pcs H-Beam Connecting Rods+ARP Bolts compatible for Toyota Tundra compatible for Lexus 1UR 4.6L 3UR 5.7L

  • * H-Beam con rods compatible for Toyota 1UR 4.6L / 3UR 5.7L
  • * Advertised Horsepower Rating: 800+HP
  • * Material: Titanizing Forged 4340 aircraft chrome moly quality steel
  • * Dimensions: Center to center length: 147.5mm; Big end diameter: 56mm; Small end diameter: 22mm ( tapered small end); Big end width: 20.8mm; Small end width: 20.8mm
  • * Package Contents: 8 Pieces of H-Beam Connecting Rods; 16 Pieces of ARP 2000 3/8" Bolts (Note: Extra cost for upgrading to ARP L19 bolts)
  • * Performance Con Rods
  • * Advertised RPM Rating: 7000-9000 rpm
  • * Fastener Tensile Strength (psi):200,000 - 230,000 psi
  • * Balanced to within +/- 1 gram per end
  • * The big end bores are honed to a +/-.01mm tolerance
  • * Heat-treating & Shot-peened for remained consistent and strong
Stock In Stock
Item Number 3002035054

MORE OPTIONS

Combination offer

  • A
  • B
  • C
  • D
  • E
  • F
  • G
CR-TOY-13UR-T
CR-TOY-13UR-T
High Quality Components
High Quality Components
With Standard ARP 2000 Bolts(Upgradable ARP L19)
Precision Machining Manufacturing
Precision Machining Manufacturing
Shot Peening for improved fatigue life. 100% CNC machined for superior tolerances, Precision rod cap alignment dowels
Professional H-Beam Design
Professional H-Beam Design
Improve stiffness, reduce stress risers and reduce weight
High Performance Material
High Performance Material
Titanizing Forged 4340 aircraft chrome moly quality steel for racing

Application

2007-2017 compatible for Lexus LS 460 & LS 460 L
2005-2011 compatible for Lexus For GS 460
2008 Present compatible for Lexus LX 570
2010 present compatible for Lexus GX 460
2010 present compatible for Toyota Tundra
2007 Present compatible for Toyota Tundra
2008 Present compatible for Toyota Sequoia
2008 Present compatible for Toyota Land Cruiser 200 Series – US and Middle East markets only
2012 compatible for Toyota Land Cruiser (China, Middle East and Australia)
2009-2013 compatible for Toyota Crown Majesta
2010–2012 compatible for Toyota Sequoia
2009–2013 compatible for Toyota Tundra
2009–2014 compatible for Toyota Sequoia
2014 compatible compatible for Toyota Tundra

Specification

Performance Con Rods
Engine Model: Compatible compatible compatible for Toyota 1UR 4.6L / 3UR 5.7L
Quantity: 8 Pieces a set
Bolts: Including Genuine 3/8" ARP 2000 bolts (Note: Extra cost for upgrading to ARP L19 bolts)
Type: H-Beam Connecting Rod
Material: Titanizing 4340 aircraft chrome moly quality steel for racing
Weight tolerance: Balanced to +/- 1 gram in set
Accessories: You will get exactly as shown in the picture above
Condition: New
Warranty: one year warranty for any manufacturing defect

Dimensions

Center to center length: 147.5mm
Big end diameter: 56mm
Small end diameter: 22mm
Big end width: 20.8mm
Small end width: 20.8mm

Feature

- Forged SAE 4340 Chrome Moly Steel for the highest strength and durability, dedicated for Racing
- Designed and processed by CNC machine.
- All big and small ends are finished with SUNNEN honing machine
- Precision alignment sleeves positively locate the rod cap, maintaining big end bore size and eliminating cap walk
- 100% X-rayed, sonic tested and magnafluxed
- Multi-stage heat treated
- Shot peened to relieve stress
- Come with the bronzed bushing suitable for the floating piston pin

Notice

- Professional installation is highly recommended (No Instruction Included)
- Custom Service:If there's no conrods you need on our site, we would be happy to help determine your requirements and develop a solution with you to satisfy your needs.
