Oil Cooler Air Guide Shield Kit Black for 7-13 Row Cooling System Universal

Application

Universal-Suitable for 7row-13row british oil cooler，please check the size of your oil cooler before purchasing.

Specification

Type: Oil Cooler Air Guide Kit
Material: Aluminum Alloy
Thickness: 1.0 mm
Color: Black
Surface: Plastic Spraying

Package included

1*Top Cover
1*Base Plate
1*Narrow Side Plate b1
1*Narrow Side Plate b2
1*Wide Side Plate b3
1*Wide Side Plate b4
1* Installation Accessories Kit
(As Shown in the Picture)

Feature

1. This air guide kit is made of high quality aluminum alloy with surface plastic spraying which can be more corrosion-resistant and durable.
2. The air guide kit can make the contact area between the air and the oil cooler greater. By concentrating the air flow, it can cool the oil in the oil cooler more efficiently to achieve optimal cooling effect.
3.The narrow side plates and wide side plates are both composed of two plates which include one with a long slotted hole. You can slide two narrow or wide plates vertically to adjust the size of the air guide kit according to the size of the oil cooler and fix two plates through the screw holes in the other side plate.
4. The air guide’s top cover and base plate can be interchanged to achieve either a left-facing or right-facing air intake. You can choose the orientation based on the vehicle's installation position.

Note

1. This air guide kit is designed to fit the Maxpeedingrods universal engine oil cooler, and it is suitable for the 7row-13row British oil cooler. When applying to other oil coolers, please check the size of your oil cooler before purchasing.
2. Professional Installation is Highly Recommended.
3. The item description was measured by hand, it could have 1-2 inches deviation.
