H-Beam Connecting Rods compatible for Audi/VW V6 Engine 2.6L 2.8L 2.7T 154mm Conrods

  • * H-Beam con rods compatible for Audi B5 S4 quattro 2.7T
  • * Performance Con Rods Advertised Horsepower Rating: 800HP
  • * Material: Forged 4340 aircraft chrome moly quality steel
  • * Dimensions: Center to center length: 154mm; Big end diameter: 57.6mm; Small end diameter: 21mm; Big end width: XX; Small end width: XX
  • * Package Contents: 6 Pieces of H-Beam Connecting Rods; 12 Pieces of ARP 2000 5/16" Bolts (Note: Extra cost for upgrading to ARP L19 bolts)
  • * Performance Con Rods
  • * Advertised RPM Rating: 7000-9000 rpm
  • * Fastener Tensile Strength (psi):200,000 - 220,000 psi
  • * Balanced to within +/- 1 gram per end
  • * The big end bores are honed to a +/-.01mm tolerance
  • * Heat-treating & Shot-peened for remained consistent and strong
Stock In Stock
Item Number 3002906706

Combination offer

  • A
  • B
  • C
  • D
  • E
  • F
  • G

Application

Compatible for Audi B5 S4 quattro 2.7T

Compatible for VW Compatible for Audi V6 Engines 2.6L, 2.7 T 30V, 2.8L 12V

Specification

Type: Forged 4340 aircraft chrome moly quality steel for racing

H-beam Conrods Quantity: 6 Pieces as showing in picture

Bolts: Including Genuine ARP 2000 bolts

Note: Extra cost for upgrading to ARP L19 bolts

Bolts Size: Genuine ARP 2000 5/16" bolts

Tolerance: Balanced to +/- 1 gram in set

Piston Bolt Hole: +-4/1000mm

Power: 600hp ~ 800PS per set

Strength of the fastening (PSI): 220,000/230,000 PSI Torque: 48ft ≈ 65 NM

Top acceleration: 7000rpm

warranty: one year warranty for any manufacturing defect

Dimensions

Center to center length: 154mm

Big end diameter: 57.6mm

Small end diameter: 21mm

Big end width: xx

Small end width: xx

Feature

- Forged SAE 4340 Chrome Moly Steel for the highest strength and durability, dedicated for Racing

- Designed and processed by CNC machine.

- All big and small ends are finished with SUNNEN honing machine

- Precision alignment sleeves positively locate the rod cap, maintaining big end bore size and eliminating cap walk

- 100% X-rayed, sonic tested and magnafluxed

- Multi-stage heat treated

- Shot peened to relieve stress

- Come with the bronzed bushing suitable for the floating piston pin

Note

Professional installation is highly recommended (No Instruction Included)

Custom Service: If there's no conrods you need on our site, we would be happy to help determine your requirements and develop a solution with you to satisfy your needs.

Learn more about CUSTOM SERVICE
