- * H-Beam con rods compatible for Audi A4 A6 RS4 Quattro 2.7T
- * Advertised Horsepower Rating: 800HP
- * Material: Forged 4340 aircraft chrome moly quality steel
- * Dimensions: Center to center length: 154mm; Big end diameter: 56.8mm; Small end diameter: 21.01mm; Big end width: 20.12mm; Small end width: 21.92mm
- * Package Contents: 6 Pieces of H-Beam Connecting Rods; 12 Pieces of ARP 2000 5/16" Bolts (Note: Extra cost for upgrading to ARP L19 bolts)
- * Advertised RPM Rating: 7000-9000 rpm
- * Fastener Tensile Strength (psi):200,000 - 220,000 psi
- * Balanced to within +/- 1 gram per end
- * The big end bores are honed to a +/-.01mm tolerance
- * Heat-treating & Shot-peened for remained consistent and strong
Compatible for Audi A4 RS4 V6 Quattro
Compatible for the compatible for Audi RS4 B5 AZR/ASJ
Note: Please confirm the dimensions before purchase the connecting Rods
Note the Big end diameter:56.8mm/2.236in
Type: Forged 4340 aircraft chrome moly quality steel for racing
H-beam Conrods Quantity: 6 Pieces as showing in picture
Bolts: Including ARP 2000 bolts
Note: Extra cost for upgrading to ARP L19 bolts
Bolts Size: Genuine ARP 2000 5/16" bolts
Tolerance: Balanced to +/- 1 gram in set
Piston Bolt Hole: +-4/1000mm
Advertised Horsepower Rating: 200HP/piece
Strength of the fastening (PSI): 220,000/230,000 PSI Torque: 48ft ≈ 65 NM
Top acceleration: 7000rpm
warranty: one year warranty for any manufacturing defect
Center to center length: 154mm/6.063in
Big end diameter:56.8mm/2.236in
Small end diameter:21mm/0.827in
Big end width:20.1mm/0.791in
Small end width: 21.9mm/0.862in
- Forged SAE 4340 Chrome Moly Steel for the highest strength and durability, dedicated for Racing
- Designed and processed by CNC machine.
- All big and small ends are finished with SUNNEN honing machine
- Precision alignment sleeves positively locate the rod cap, maintaining big end bore size and eliminating cap walk
- 100% X-rayed, sonic tested and magnafluxed
- Multi-stage heat treated
- Shot peened to relieve stress
- Come with the bronzed bushing suitable for the floating piston pin
Professional installation is highly recommended (No Instruction Included)
Custom Service:If there's no conrods you need on our site, we would be happy to help determine your requirements and develop a solution with you to satisfy your needs.
