10T Hydraulic Wire Crimper Tool Set with 9 Dies for Electrical Cable Battery

Specification

1. Great for battery and welding cables, power wires and electrical cables etc
2. Fits for: 1/8" to 3/16" (12 AWG to 2/0 AWG) Copper and aluminum wires
3. The crimping range is from 4 to 70 mm2 to suit for different size demands.

Most Under Pressure: 10T
Max Stroke: 10mm/0.39 in
Crimping Type: hexagon
Crimping Form: Confining Pressure
Crimping Range: Cu 4-70mm²
Crimping Die Qty: 9 pairs
Mold Configuration: 4, 6, 8，10, 16, 25, 35, 50, 70mm²
Hydraulic oil: 7-32 mechanical oil
Packing: Plastic box+Packing box

Package included

1Pc 10 ton crimper
9Pc Dies
1Pc Plastic compatible for case

Feature

1. On/off knob for fast tool operation.
2. 8" Long comfortable grips，More convenient and secure crimping operations，Comes with a durable plastic compatible for case
3. This Hydraulic Crimper is a very professional and easy tool for crimping aluminum and cooper or other types of metal
4. 9 sets of the largest hexagon crimping dies,which are made of hardened steel with chrome finish.
5. Easy and Safety to Use On/off knob for fast tool operation,
Adjustable oil return valve,which has longer service life and no oil leakage,More convenient and secure crimping operations.

Note

1.It is necessary to select a crimping mold according to the wire specification and the corresponding copper/aluminum terminal (aluminum terminal needs to be crimped with a larger mold).
2. Improper crimping dies will cause the crimping between the wire and the copper/aluminum terminal to be not tight or produce a lot of flash
